| Recommended Drone Size | 7" & 10" Drone |
|---|---|
| Firmware | STM32F405 |
| Persistent Current | 60A*4 |
| Maximum Current | 60A (6S) |
| TVS Protective Diode | Yes |
| External Capacitor | 50V 470uF Four Solid Capacitors in Parallel |
| ESC Protocol | DSHOT300/600 |
| Power Input | 6S LiPo |
| Power Output | VBAT |
| Current Sensor | Supported (Scale =200 Offset =0) |
| Mounting | 30.5mm x 30.5mm (4mm hole diameter ) |
| Dimension | 45.0mm(L) x 44.6mm(W) x 6.1(H)mm |
| Weight | 13g |
