| Recommended Drone Size | 13" Drone |
|---|---|
| Firmware | STM32F405 |
| Persistent Current | 80A*4 |
| Maximum Current | 80A (8S) |
| TVS Protective Diode | Yes |
| External Capacitor | 50V 470uF Four Solid Capacitors in Parallel |
| ESC Protocol | DSHOT300/600 |
| Power Input | 6-8S LiPo |
| Power Output | VBAT |
| Current Sensor | Supported (Scale =200 Offset =0) |
| Mounting | 30.5mm x 30.5mm (4mm hole diameter ) |
| Dimension | 57.0mm(L) x 53.0mm(W) x 7.0(H)mm |
| Weight | 30g |
