| Image Compression | H.265 |
|---|---|
| Signal System | PAL / NTSC |
| Network | 4G |
| Positioning | GPS, Beidou, GLONASS |
| Storage | TF card up to 256GB |
| Resolution | 2.0MP |
| Noise Reduction | 2D/3D |
| Lens | 2.8mm, F2.0, 90° angle |
| Lighting | Infrared + warm light |
| Interfaces | RS485, 1 audio input/output, alarm channels |
| Communication Protocols | JT/T808, JT/T1078, GB28181 |
| Power Input | DC 9V–36V ±10% |
| Power Usage | 150mA ±10% (with infrared on) |
| Operating Temperature | -20°C to 70°C |
| Size | 118×54.9×73.2 mm |
| Weight | 370g |
