| Camera |  | ||
|---|---|---|---|
| Effect Pixels | 1920x1080 | ||
| Pixel size | 2.8μm（H）ⅹ 2.8μm（V） | ||
| TV System | NTSC / PAL | ||
| S/N ratio | 42dB | ||
| Max, Video Resolution | AHD: 2 million pixels 1080P | ||
| Minimum Illumination | 0.1LUX | ||
| Viewing angle | 150°(H) / 80°(V) | ||
| Operating Temperature | -20℃-70℃，RH95%Max | ||
| Storage Temperature | -30℃-80℃，RH95%Max |
| Radar Sensor | |
| | |
|---|---|---|---|
| Rated working voltage | 12V/24V | Horizontal angle | 130° |
| Operating voltage range | 9-32V | Vertical angle | 60° |
| Working current | ＜200mA@12V | Angle accuracy | ±0.5 @ 40° |
| Operating temperature range | -40℃ ~ +80℃ | Angular resolution | 30° |
| Storage temperature range | -40℃ ~ +85℃ | Speed Range | -300 ~ +300km/h |
| Working frequency | 77GHz | Speed Accuracy | 0.2m/s |
| Transmit power | 12dBm | Detectability | 30m |
| Modulation mode | FMCW | Distance Accuracy | 0.1m |
| Antenna form | 4TX，4RX | Distance Resolution | 0.1m |
| Data interface number | CAN | Waterproof grade | IP69K |
